UCLA 3D Printed a Zinc-Ion Battery That Stores 7x More Energy — With a $300 Consumer Resin Printer

A team at UCLA used a consumer desktop resin printer — the kind you can buy for under $300 — to build a zinc-ion battery that stores more than seven times the energy of comparable designs. The result matters less for what the battery is and more for how it was made.

The Number

The battery stores “more than seven times as much energy as similar devices” while retaining 82 percent of its capacity after 1,500 charge cycles. Published in Small journal as “High Mass-Loading Vanadium Oxide on 3D Printed Carbon Lattices for Zinc-Ion Supercapacitors,” the research comes from Maher El-Kady and Ric Kaner’s group in UCLA’s Department of Chemistry and Biochemistry.

The printer: an Elegoo Mars 3 Pro resin printer, a widely available prosumer machine.

How the Math Works

The fabrication process is conceptually straightforward. The printer builds a lightweight lattice structure from standard polymer resin. That structure is then carbonized — heated at high temperature until the material converts into a conductive carbon scaffold. The scaffold is coated with vanadium oxide, which creates billions of microscopic pores that dramatically expand the electrode’s effective surface area while still allowing ion movement.

The energy improvement is surface area math. Traditional zinc-ion battery electrodes are constrained by how much active material can be packed into a given volume using conventional flat or wound electrode architectures. The 3D-printed lattice creates internal geometry that conventional manufacturing can’t easily replicate — more surface contact between the vanadium oxide and the electrolyte means more energy storage per unit volume. The carbon scaffold is the structural enabler; vanadium oxide does the storage work.

What It Signals

Zinc-ion chemistry has a cost and safety case over lithium-ion that has never fully materialized commercially. Zinc is abundant, non-flammable, and works with water-based rather than flammable electrolytes — all significant advantages for grid-scale stationary storage, where weight matters less than cost and safety. The barrier has been energy density. Traditional zinc-ion designs couldn’t approach lithium-ion’s practical threshold in applications where those material advantages would justify the switch.

The UCLA result suggests additive manufacturing may be the fabrication method that closes that gap. If lattice electrode structures can be reproduced at scale, the combination of zinc’s safety and material cost with energy density approaching lithium’s practical range could shift the economics for solar load leveling, community battery systems, and industrial backup power — applications where the operational environment favors the zinc chemistry’s properties.

The desktop printing connection is the detail the 3D printing research and industrial AM community should watch closely. This result was not produced on an industrial metal printer or a specialized research apparatus. It was produced on a prosumer resin printer available to any researcher, maker, or small lab. That accessibility changes the reproducibility dynamics for this class of electrode architecture.

Source: 3DPrint.com
